Piper Aircraft PA22-108 instrument panel
The PA22-108 panel template at the panel's dimensions, 38.13 × 10.5 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
12 panels laid out on this template
Recent PA22-108 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in a PA22-108 panel
The equipment placed most often across the 12 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Vertical Speed Indicator | 6 | 50% |
| uAvionix Corporation AV-30 PFD | 4 | 33% |
| Falcon Gauge Airspeed Indicator 3" | 4 | 33% |
| Falcon Gauge Altimeter 3" | 3 | 25% |
| uAvionix Corporation AV-30 HSI | 3 | 25% |
| Falcon Gauge Altimeter 2" | 3 | 25% |
| Garmin International, Inc GI 275 EIS | 2 | 17% |
| APPAREO Stratus ES Transponder | 2 | 17% |
