Piper Aircraft PA-18 instrument panel
The PA-18 panel template at the panel's dimensions, 27.01 × 8.91 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
207 panels laid out on this template
Also written PA18 or PA 18.
3 templates for the PA-18
27.01 × 8.91 in
27 × 8 in
27 × 10.74 in
Recent PA-18 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in a PA-18 panel
The equipment placed most often across the 207 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Altimeter 3" | 75 | 36% |
| Falcon Gauge Airspeed Indicator 3" | 67 | 32% |
| Sensa Technologies 7277 | 52 | 25% |
| Falcon Gauge Vertical Speed Indicator | 40 | 19% |
| Garmin International, Inc GI 275 EIS | 36 | 17% |
| Garmin International, Inc G5 | 34 | 16% |
| Airpath Instrument Company Panel Mount Compass | 31 | 15% |
| Aircraft Spruce & Specialty Co 1040 Ball Bank Indicator | 27 | 13% |
