Piper Aircraft PA-46-500 instrument panel
The PA-46-500 panel template at the panel's dimensions, 51.32 × 20.88 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
14 panels laid out on this template
Recent PA-46-500 panel designs
Exported by builders from the Panel Designer, newest first.
PA-46-500 for sale
Selling a PA-46-500? List it on the Hangar Flying Marketplace, where builders and owners look.
What builders put in a PA-46-500 panel
The equipment placed most often across the 14 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin International, Inc G3X Touch | 3 | 21% |
| Garmin International, Inc GFC 600 | 3 | 21% |
| Garmin International, Inc GMC 507 | 2 | 14% |
| Garmin International, Inc GTN 635 | 2 | 14% |
| Garmin International, Inc GNC 255 | 2 | 14% |
| Garmin International, Inc GMA 245 | 2 | 14% |
| Garmin International, Inc G5 | 2 | 14% |
| Garmin International, Inc GI 275 ADI | 2 | 14% |
