Piper Aircraft PA-30 instrument panel
The PA-30 panel template at the panel's dimensions, 47.75 × 16.81 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
48 panels laid out on this template
Also written PA30 or PA 30.
Recent PA-30 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in a PA-30 panel
The equipment placed most often across the 48 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Falcon Gauge Airspeed Indicator 3" | 14 | 29% |
| Falcon Gauge Altimeter 3" | 14 | 29% |
| Garmin International, Inc GFC 500 | 13 | 27% |
| Falcon Gauge Vertical Speed Indicator | 13 | 27% |
| Garmin International, Inc GI 275 ADI | 12 | 25% |
| Garmin International, Inc G5 | 9 | 19% |
| Garmin International, Inc GI106B | 9 | 19% |
| Garmin International, Inc GI 275 HSI | 8 | 17% |
Other Piper Aircraft panels
From layout to fabricated panel
Lay out the PA-30 panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
