Van's Aircraft RV-6 instrument panel
The RV-6 panel template at the panel's dimensions, 41.54 × 11.91 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
551 panels laid out on this template
Also written RV6 or RV 6.
Recent RV-6 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an RV-6 panel
The equipment placed most often across the 551 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Sensa Technologies 7277 | 186 | 34% |
| Garmin International, Inc G5 | 161 | 29% |
| Garmin International, Inc G3X Touch | 141 | 26% |
| ACK Technologies ELT | 135 | 25% |
| Garmin International, Inc GTR 200 | 112 | 20% |
| Garmin International, Inc GMC 507 | 107 | 19% |
| Falcon Gauge Airspeed Indicator 3" | 99 | 18% |
| Dynon Avionics Autopilot Panel | 94 | 17% |
Other Van's Aircraft panels
From layout to fabricated panel
Lay out the RV-6 panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
