Van's Aircraft RV-4 instrument panel
The RV-4 panel template at the panel's dimensions, 25.96 × 10.23 inches. Lay out your instruments and avionics on it to scale, export the picture and the equipment list, or send it to our shop for CAD, Cut, Paint & Label.
390 panels laid out on this template
Also written RV4 or RV 4.
3 templates for the RV-4
25.96 × 10.23 in
25.96 × 10.23 in
25.96 × 10.23 in
Recent RV-4 panel designs
Exported by builders from the Panel Designer, newest first.
What builders put in an RV-4 panel
The equipment placed most often across the 390 designs on this template. Counts, never names.
| Equipment | Designs | Share |
|---|---|---|
| Garmin International, Inc G5 | 122 | 31% |
| Garmin International, Inc G3X Touch | 73 | 19% |
| Sensa Technologies 7277 | 70 | 18% |
| Falcon Gauge Altimeter 3" | 64 | 16% |
| Garmin International, Inc GMC 507 | 59 | 15% |
| Falcon Gauge Airspeed Indicator 3" | 59 | 15% |
| Dynon Avionics Autopilot Panel | 58 | 15% |
| ACK Technologies ELT | 57 | 15% |
Other Van's Aircraft panels
From layout to fabricated panel
Lay out the RV-4 panel in the Panel Designer, then send it to our shop for CAD, Cut, Paint & Label.
